Descriptions
A 180-degree AP style network CAT6A UTP 8P8C RJ45 Keystone jack (TP-5228-C6AU8) refers to a type of modular connector used in structured cabling systems, particularly for Ethernet networks.
Let's break down what each part of the term means:
180-degree: This refers to the design of the Keystone jack where the RJ45 connector is in a straight-through alignment, without any angle or bend. This design is sometimes preferred for installations where cables need to run straight without deviation.
Network CAT6A: This indicates the performance category of the Keystone jack. CAT6A (Category 6A) supports higher data rates and frequencies compared to CAT6, making it suitable for high-speed Ethernet networks, including 10 Gigabit Ethernet.
UTP: Stands for Unshielded Twisted Pair, referring to the type of cable typically used with the Keystone jack. UTP cables are commonly used in Ethernet networks and do not have additional shielding around the twisted pairs of wires.
8P8C RJ45: Specifies the connector type used in the Keystone jack. RJ45 connectors are standard for Ethernet connections and have 8 positions and 8 contacts (8P8C), allowing for connectivity to all 8 wires within a CAT6A cable.
Keystone jack: A Keystone jack is a modular connector that fits into a Keystone wall plate, patch panel, or surface mount box. It provides a standardized interface for terminating Ethernet cables and supports easy customization and configuration of network connections.
In summary, a 180-degree AP style network CAT6A UTP 8P8C RJ45 Keystone jack is a specific type of modular connector designed for high-speed Ethernet networks (CAT6A), with a straight-through alignment (180-degree) of the RJ45 connector. It is used in structured cabling systems to provide reliable and standardized connectivity for Ethernet cables.
Main Features
The main features of a 180-degree AP style network CAT6A UTP 8P8C RJ45 Keystone jack typically include:
High-Speed Performance: Designed for CAT6A cables, which support bandwidth up to 10 Gigabit Ethernet (10GbE), ensuring reliable high-speed data transmission.
180-Degree: The RJ45 connector is aligned in a straight-through (180-degree) configuration, allowing cables to run straight without any bend or angle. This can simplify installation and ensure consistent connectivity.
Compatibility: Compatible with standard CAT6A UTP cables, which are widely used in Ethernet networks for various applications including data centers, offices, and residential environments.
Modular Design: Keystone jacks are modular connectors that fit into Keystone-compatible wall plates, patch panels, or surface mount boxes. They provide flexibility in configuring and organizing network connections as needed.
Reliability: Ensures secure termination of cables with proper contact alignment and retention, maintaining signal integrity and reducing the risk of connection issues or data loss.
Versatility: Supports a variety of Ethernet applications and environments, including those requiring higher data rates and performance levels typical of CAT6A standards.
Ease of Installation: Keystone jacks are designed for easy installation and termination, often requiring standard punch-down tools for UTP cables, which simplifies deployment in structured cabling systems.
Overall, the main feature of a 180-degree AP style network CAT6A UTP 8P8C RJ45 Keystone jack is its capability to provide robust, high-speed Ethernet connectivity with a straight-through alignment, ensuring reliability, compatibility, and ease of installation in various networking setups.
Schematic Diagrams
Packing Pictures
Order Data
| Item No |
Descriptions |
| TP-5228-C6AU8 |
Keystone jack, CAT6A, UTP, 8P8C, 180 degree, AP style |
